Uppþvottavökvi áfyllingarvél

A dishwashing liquid filling machine is a type of automated equipment that is designed to fill bottles or containers with dishwashing liquid. It typically uses a series of pumps, sensors, and nozzles to accurately measure and dispense the correct amount of dishwashing liquid into each container. These machines can be used in industrial or commercial settings to increase production efficiency and accuracy.

Tæknilýsing

uppþvottalykivél
1. With CE Certificate,Meet the GMP
2. Material:304or316Stainless Steel
3. Pay:T/T,L/C

Lýsing

CE ESB
ISO9001
Uppfylli kröfur GMP
longlife of service, low mainteinance rate

Aðalaðgerð

Vélin er háþróuð fyllingarvél með mikilli nákvæmni sem getur klárað aðferð flösku við að telja, fylla og lokka sjálfkrafa.

Lögun

1. Samningur uppbyggður, snilld, auðveld í notkun og mjög sjálfvirk.

2. snertir íhluta við efni eru úr ryðfríu stáli, auðvelt að hreinsa upp.

3. Bensínmagn er stjórnað með filmulokum til að tryggja nákvæmni.

4. Háhraða og mjög nákvæmar fyllingarlokar tryggja engan leka.

5. Það er búið hágæða kapfóðrunarkerfi.

Málvalkostur

Monitor language: English, Spanish, Arabic, Portuguese, Russian, Italian, French, Korean.

Helstu einkenni:

1. Linear type piston filling machine special designed for sticky liquid,such as detergent, shampoo, lotion,lubricant oil,edible oil, etc. international advanced technology, already approved by well-known companies such as Bayer. High filling accuracy, simple structure, stable working, widely application. Counting of bottles inlet, qualitative filling, bottles outlet are done automatically.

2. Not only the whole 13 filling nozzles dosage can be rough adjusted, but also each single filling nozzles dosage can finely adjusted.

3. Getur lagt margar breytur á minnið, gagnlegar fyrir ýmsar forskriftir breytt, hægt er að breyta öllum fyllingarskömmtum með snertiskjá.

4. Liquid control for normal working liquid level control, sound and light alarm device, guarantee the liquid level at normal condition; also can achieved for inlet valve/pump control.

5. Material outlet joints all adopts quick-assembling type (clamp type), easily for clean. Sealing gaskets adopts fluorine rubber O-ring; sanitary connecting pipes.

6. With protection case, drip gutter, main materials are made of SS304, wetted parts are made of SS316L.

Helstu tæknilega færibreytur

Liður	Nafn	Tæknilegar breytur
01	Vélvídd (L * W * H)	2200mm * 1400mm * 2800mm
02	Þyngd vélarinnar	Um 1400Kg
03	Innri þvermál gáma	≥φ35mm
04	Hentugur ílát	1Liter .2Liter
05	Gámahæð	80-350mm
06	Aflgjafi	AC 380V; 50 HZ
07	Kraftur	5Kw
08	Fylla nákvæmni	≤ ± 1%
09	Loft uppspretta	0,6Mpa stöðugt og hreint þjappað loft
11	Fjöldi stútpúða	13
12	Færibönd	900mm ± 50mm
13	getu	≤3200 flaskar / klukkustund (taktu vatn sem próf)
14	Flaskan í fóðurstefnu	Frá vinstri til hægri

Fljótlegar upplýsingar

Gerð: Bensínvél
Skilyrði: Nýtt
Notkun: Chemical
Gerð umbúða: Flöskur
Pökkunarefni: Viður
Sjálfvirk einkunn: Sjálfvirk
Drif gerð: Pneumatic
Spenna: 220v
Afl: 3KW
Upprunastaður: Shanghai. Kína (meginland)
Vörumerki: VKPAK
Mál (L * W * H): 2200mm * 1400mm * 2800mm
Þyngd: 1400
Vottun: CE
Þjónustuþjónusta veitt: Verkfræðingar tiltækir þjónustu véla erlendis
efni: SS304
PLC: Panasonic
Snertiskjár: Panasonic

Dishwashing liquid filling machines are specifically designed to package dishwashing liquids into various types of containers. These machines are essential for businesses in the cleaning industry who want to streamline their packaging process and increase their productivity. There are several types of dishwashing liquid filling machines available in the market, each with its unique features and benefits.

One of the most popular types of dishwashing liquid filling machines is the volumetric filler. This machine operates on the principle of displacement and uses a piston to fill the containers with the precise amount of liquid required. This type of machine is highly accurate and is suitable for packaging liquids with a constant viscosity.

Another type of dishwashing liquid filling machine is the gravity filler. This machine works on the principle of gravity and uses a funnel to fill the containers with the liquid. The liquid is then dispensed into the containers based on the height of the liquid in the funnel. This type of machine is ideal for packaging low viscosity liquids and is very cost-effective.

The third type of dishwashing liquid filling machine is the overflow filler. This machine works on the principle of overflow and uses a hopper to fill the containers with the liquid. The liquid is then dispensed into the containers based on the height of the liquid in the hopper. This type of machine is ideal for packaging high viscosity liquids and can handle liquids with large particles.

When choosing a dishwashing liquid filling machine, it is important to consider factors such as the size of your production line, the viscosity of the liquid, the type of containers you will be using, and the speed of production you require. It is also important to consider the ease of maintenance and the reliability of the machine.

In conclusion, a dishwashing liquid filling machine is a crucial investment for businesses in the cleaning industry. With the right machine, businesses can increase their productivity, improve the quality of their packaging, and save time and money. When choosing a dishwashing liquid filling machine, it is important to consider factors such as the size of your production line, the viscosity of the liquid, the type of containers you will be using, and the speed of production you require.
